Installing the batteries
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE: Dell Pro Rugged 13 RA13250 can accommodate two swappable batteries (primary and optional). The removal
procedure of the primary and optional batteries are identical.
NOTE: BIOS displays a battery error when non-Dell Pro Rugged 13 RA13250 batteries are used.
The following images indicate the location of the right and left batteries and provide a visual representation of the installation
procedure.
Figure 15. Installing the left-side battery
Removing and installing Customer Replaceable Units (CRUs)
51
