Base cover
Removing the base cover
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the batteries.
3. Remove the solid state drive carrier.
About this task
The following images indicate the location of the base cover and provide a visual representation of the removal procedure.
Figure 45. Removing the base cover
Removing and installing Field Replaceable Units (FRUs)
79
