Steps
1. Place the base cover at an angle on the computer chassis, then route the battery cables along the designated chassis slot.
2. Connect the left and right battery cables to the connectors on the system board.
3. Replace the 27 (M2.5x5) and four (M2.5x3) screws that secure the base cover to the computer chassis.
Next steps
1. Install the solid state drive carrier.
2. Install the batteries.
3. Follow the procedure in after working inside your computer.
Stylus holder
Removing the stylus holder
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the stylus.
3. Remove the batteries.
4. Remove the solid state drive carrier.
5. Remove the base cover.
About this task
The following image indicates the location of the stylus holder and provides a visual representation of the removal procedure.
84
Removing and installing Field Replaceable Units (FRUs)
