Figure 19. Removing the handle
Steps
1. Remove the two (M3.5x8) screws that secure the handle to the computer.
2. Remove the handle from the computer.
Installing the handle
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
NOTE: The handle screw is part of the handle assembly and cannot be ordered separately.
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the handle and provides a visual representation of the installation procedure.
56
Removing and installing Field Replaceable Units (FRUs)
