Figure 20. Installing the handle
Steps
1. Align the screw holes on the handle with the screw holes on the computer.
2. Replace the two (M3.5x8) screws to secure the handle to the computer.
Next steps
1. Follow the procedure in after working inside your computer.
Keyboard
Removing the keyboard (standard)
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the batteries.
About this task
The following images indicate the location of the keyboard and provide a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
57
