1. Base cover
2. Rigid handle
3. Memory module
4. Left USB Type-C board
5. Heat sink
6. Fan
7. Left I/O-board
8. System board
9. Keyboard
10. Palm-rest assembly
11. Speakers
12. Display assembly
13. Coin-cell battery
14. Keyboard LED board
15. Power button with fingerprint reader
16. USH board
17. Solid state drive
18. Power-button board
19. RF switch board
20. Right USB Type-C board
21. WWAN module
22. Battery
NOTE:
Dell provides a list of components and their part numbers for the original computer configuration purchased. These
parts are available according to warranty coverage purchased by the customer. Contact your Dell sales representative for
purchase options.
