107
Figure 106: System Image
The system image contains fundamental information on the AST40 system.
The following data can also be added:
• all the screwdriving programs
• screwdriving results
• Curve displays on the latest screw assemblies.
IMPORTANT
It is strongly recommended that all available data be included in the
system image.
After clicking on the button "Generate", a dialog box opens in which you can specify the
name and save location of the system image.
