42
3.
In the following dialog window user-s
pecific changes can be made to the name
"Final Name" and the description "Descripti
on" (it is recommended to keep the
name and the description!),
Then confirm with "OK".
Figure 16:
Import AST40_Cntrl.L5X – Final Name
4.
The added elements are now
visible in the menu tree:
Figure 17:
Import AST40_Cntrl.L5X – Menu tree
