30
 An incorrect output module has been entered in the hardware configuration.
Output module 2 must be configured with "64 bytes out".
 Incorrect start address of the output module 2 at the interface parameter
O_Addr2
FF13
Error while writing to the output module 3 (O_Addr3)
Possible causes:
 An incorrect output module has been entered in the hardware configuration.
Output module 3 must be configured with "64 bytes out".
 Incorrect start address of the output module 3 at the interface parameter
O_Addr3
FF14
Error while writing to the output module 4 (O_Addr4)
Possible causes:
 An incorrect output module has been entered in the hardware configuration.
Output module 4 must be configured with "32 bytes out".
 Incorrect start address of the output module 4 at the interface parameter
O_Addr4
F100
Timeout error in the fieldbus communication
Table 13: Status Signal Error Codes
