Deprag AST40-1 User Manual

82
Figure 73: Diagnosis Fieldbus, Program Selection (Page 3)
All the inputs for Profibus / Profinet are described in section 7.6.1.3.2 Description of the
data structure of the control signals (UDT21) and for EtherNet/IP in section 7.6.2.4.4
Description - data structure AST40_OUT_Signals.
Designation
AST40 Profibus / Profinet EtherNet/IP
Program ProgramNo PROG_NR
Table 28: Diagnosis Fieldbus, Program Selection (Page 3)
Press the key , to get to the next diagnostics page or , to go the previous diagnosis
page.
Figure 74: Diagnosis Fieldbus, Outputs (Page 4)
