Deprag AST40-1 User Manual

17
6.2.8 Fieldbus interface (optional)
6.2.8.1 Profibus
Designation: GX10
Plug connector: SUB-D 9-pole (bushing)
Pin Designation Description
1 -- --
2 -- --
3 RX/TX-P Send / Receive data ; Data line B
4 PB_RTS
5 PB-GND Mass (Ground):
6 PB-5V Voltage supply +5V
7 -- --
8 RX/TX-N Send / Receive data ; Data line A
9 -- --
Table 8: Configuration Interface Profibus
6.2.8.2 Profinet
Designation: GX10
Plug connector: 2x Female connector RJ45 BULGIN PX0833
6.2.8.3 EtherNet/IP
Designation: GX10
Plug connector: 2x Female connector RJ45 BULGIN PX0833
6.2.8.4 EtherCAT
Designation: GX10
Plug connector: 2x Female connector RJ45 BULGIN PX0833
