7.6.1.3.2 Description of the data structure of the control signals (UDT21)
Designation Data type Description
ReleaseStart BOOL
Clearance to start for the AST40
This signal is currently not available yet!
Start BOOL
Clearance to start for the AST40
When the status of the start signal changes from "low" to
"high", the pre-selected screwdriving program is started in
the sequence controller ASTS40. The start signal must be
present until the screwdriver operation has ended.
ProgIn1 BOOL
Input 1 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn2 BOOL
Input 2 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn3 BOOL
Input 3 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn4 BOOL
Input 4 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn5 BOOL
Input 5 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn6 BOOL
Input 6 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn7 BOOL
Input 7 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn8 BOOL
Input 8 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn9 BOOL
Input 9 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
ProgIn10 BOOL
Input 10 for the screwdriver program
This input can be scanned in the screwdriving program of
the AST40 sequence control to stop or continue the
screwdriving program.
