G
Click [OK].
H
Open the front cover.
I
Remove the correction pin and jig.
Detection pin for
correction
ATC magazine
correction jig
Rotary axis correction jig
J
Close the front cover.
MEMO
To check whether the following symptoms have been improved, actually output milling data�
• When the milling position is misaligned
• When symptoms such as a level dierence or a hole in the Z direction occur in the milling results
"
Periodic Care and Maintenance
60
3. Maintenance
