F
Attach the adapter to the machine.
" P.43 "Step 2: Attaching the Adapter to the Machine"
For Pin-type Workpieces
Required Items
Adapter Pin-type workpiece
Pin-type workpiece
adapter
Torque screwdriver
1.
Mount the pin-type workpiece adapter on the adapter.
A
Use a torque screwdriver to loosen the adapter screws, turning them approximately 4
times (4 locations).
Starting Milling
37
Chapter 2 Milling
Use the included spare screws when a screw
is lost or worn.
To Next Page
