Screw the cap with the two tubes tightly onto the empty 10L tank and connect the two tubes to the
connections on the back of the instrument (WASTE OUTLET). Both the red and the blue connector can
be used.
ATTENTION
In order for the “too-full” probe to function properly, the cap must be perfectly screwed on, until
compressing the O-ring.
b) If the tank supplied with the instrument is not used, it is advised to order a cap suitable for the
tank model in use from the manufacturer, in order to ensure that the cap connection to the empty bottle
is sealed to guarantee correct function of the “too-full” sensor.
3.2.3.2 Connection to a centralized waste disposal system
This operation must be performed with the instrument switched off.
In this case, only the connection with the red band can be used to connect to the drainage.
If a suitable connection is required, it can be ordered from DIESSE Diagnostica Senese SpA,
specifying the features of the connection needed.
3.2.4 I NTRODUCTION OF PAPER
A roll of thermal paper required for the printer is available in the tank compartment. (fig. 20). The paper
can be replaced, with the instrument switched on or off, as follows:
Place the roll of paper in the relative slot.
With the instrument switched on :
- Pass the paper through the slot, the printer will advance the paper and then stop
automatically.
- Be sure that the heat-sensitive side of the paper faces the operator.
- Switch the instrument off and on again to set the printer error.
With the instrument switched off
- Raise the internal lever pulling it towards the operator (see fig.21).
- Pass the paper into the slot until it comes out.
Be sure that the heat-sensitive side of the paper faces the operator.
- Push down the lever until its mechanical stop.
- Start up the instrument again to set the printer error.
