Specifications
General Specifications
A/D Converter: 24-bit high performance audio
D/A Converter: 24-bit high performance audio
Sampling Frequency: 44.1 kHz throughout
DSP Section: 4 Audio DNA
TM
DSP Processors
Preset Memory: 65 User Presets
65 Factory 1 Presets
65 Factory 2 Presets
Analog Input Connections:
Guitar Input:
1/4” Unbalanced (Tip-Sleeve)
Input Impedance: 475 kOhms
Mic Preamp Input: XLR Balanced (Female XLR, pin 2 Hot)
Phantom Power: +15V
Input Impedance: 600 Ohms balanced
Maximum Input Level: -22 dBu with mic input level set to max, or -2 dBu
with mic input level set to max
Line Inputs: 1/4” Balanced (Tip-Ring-Sleeve) or Unbalanced
Input Impedance: 20 kOhms Balanced, 10kOhms Unbalanced
Maximum Input Level: +22 dBu
Analog Output Connections:
LINE OUTPUTS: 1/4 Impedance Balanced or Unbalanced
Output Impedance: 1 kOhm per side
Maximum Output Level: +22 dBu
BALANCED OUTPUTS: Male XLR
Output Impedance: 120 Ohms
Maximum Output Level: +22 dBu
Headphones: 1/4” Stereo (Tip = Left, Ring = Right, Sleeve =
Ground)
100 mW per channel at 50 Ohms
Digital Connections:
Footswitch: 1/4” jack (compatible with optional GNXFC)
MIDI In: 5-pin Din
MIDI Out/Thru: 5-pin Din
Universal Serial Bus (USB): Type B, supports USB1.1 Full Speed (12 Mbps
Bandwidth USB 2.0 compatible)
130
Specifications
GNX3000 Owner’s Manual
