CHAN ONE EQ and CHAN TWO EQ Rows

STATUS

BUTTON

KNOB

CHAN ONE EQ & CHAN TWO EQ ROWS

The CHAN ONE EQ and CHAN TWO EQ rows are used for modifying the center

frequencies of the Bass, Midrange, and Treble controls of that reside within the TONE

Row. There is also a Cabinet Tuning control for changing the tuning of a selected

channel’s cabinet resonance, and a Presence control is available here for editing amp

tone as well. When either the CHAN ONE EQ

or CHAN TWO EQ row is selected, the

knobs and STATUS

button perform the following functions:

Status button

Turns the EQ on and off for the selected channel.

Knob 1

Adjusts the Cabinet Tuning resonance of the cabinet model for the selected

channel. The Cabinet Tuning ranges are from one octave below (

-12.0) to one

octave above (

12.0).

Knob 2

Selects the Bass Center Frequency for the selected channel. The Bass Center

Frequency range is from 50Hz (

50 hz) to 300Hz (300 hz).

Knob 3

Selects the Midrange Center Frequency for the selected channel. The Midrange

Center Frequency range is from 300Hz (

300 HZ) to 5000Hz (5000 HZ).

Knob 4

Selects the Treble Center Frequency for the selected channel. The Treble Center

Frequency range is from 500Hz (

500 HZ) to 8000Hz (8000 HZ).

Knob 5

Boosts or cuts the Presence Level for the selected channel. The Presence Control

is a shelf EQ and has a fixed frequency of 7500Hz. The Presence Level range is

from -12dB

(-12) to 12dB (12).

GNX3000 Owner’s Manual
