GNX3000 Owner’s Manual
Audio Routing Setups
Setups Introduction
The GNX3000 is equipped with four inputs and four outputs that can be configured
several different ways for both live and recording applications. These settings determine
which pair of outputs the guitar processing, MIC and LINE INPUTS are routed to and
how the MIC or LINE INPUTS are routed through the GNX3000’s effects processing.
For example, today you may be practicing with headphones, tomorrow you may be
recording on your computer, and next week you might be performing at a club, running
your guitar and vocals through monitors and a PA system. The GNX3000 has different
input/output options that are designed for each of those situations, and more.
Output Setups
The GNX3000 features both 1/4" and XLR OUTPUTS on the rear panel. These jacks let
you simultaneously connect the GNX3000 to an amplifier/speaker system on stage via
the 1/4" OUTPUTS and connect directly to your PA system via the XLR OUTPUTS.
Press the OUTPUT SETUP button and turn the DATA WHEEL to select one of the Output
Setup options. Press the EXIT button to save your selection.
