Whammy
Whammy is an effect that uses the EXPRESSION PEDAL to bend the pitch of the
incoming signal, or add a bendable harmony with the original signal. As the
Pedal is moved, the note bends either up or down. When Whammy is selected, it is
automatically placed before the Amp Modeling as shown in the block diagram (see
page 50). The Whammy effect must be linked to the Expression Pedal in order to
function. See page 75 for more information on linking the EXPRESSION PEDAL
.
Parameter 1
KNOB 2 selects the interval and direction of the pitch bend. Choices are as follows:
Whammy (no Dry Signal)
1 oct up (one octave up)
2 oct up (two octaves up)
2nddown (2nd down)
rev2nddn (2nd down
reversed pedal
action)
4th down (one 4th down)
1 oct dn (one octave down)
2 oct dn (two octaves down)
divebomb (Dive Bomb)
Harmony Bends (Dry Signal
Added)
m3->maj3 (a m3rd to a
Maj3rd)
2nd->maj3 (a 2nd above to a
Maj3rd up)
3rd->4th (a Maj3rd above to a
4th up)
4th->5th (a 4th above to a
5th up)
5th->oct (a 5th above to an
octave up)
h oct up (one octave up)
h oct dn (one octave down)
octup->Dn (one octave up to
one octave down)
Parameter 2
KNOB 3 provides a manual control of the Whammy Pedal (wham pdl) position.
Ranges from 0 to
99.
Knob 4
No function when the Whammy is selected.
Level
KNOB 5 adjusts the Whammy Mix (Wham mix) of all of the pitch-altering effects
in this module. Ranges from 0 to
99.
54
GNX3000 Owner’s Manual
Effects and Parameters
