Mic and Line Setups
You can configure the MIC and LINE INPUTS routing for live performance and
recording applications. The GNX3000 acts as a mixing device for
MIC and LINE
INPUTS, and can eliminate the need for a mixer when the outputs are to be plugged
directly into a full-range powered speaker system. When enabled, these inputs can be
routed around or through some or all of the effects processing and then mixed directly
into the GNX3000’s 1/4” and XLR OUTPUTS.
Use the SHIFT>MIC and SHIFT>LINE buttons along with the DATA WHEEL to select the
Mic/Line Setup options.
Mic
Button
Line
Button
Shif
t
Button
Both MIC and LINE INPUTS have four settings that can be independently selected.
They are as follows:
MIC OFF/LINE OFF - MIC and LINE INPUTS are disabled.
MIC DRY
/LINe DRY - MIC and LINE INPUTS are routed directly to GNX3000’s outputs,
bypassing all effects processing.
MIC RVB
/LINe RVB - MIC and LINE INPUTS are routed through delay and reverb effects
of the current preset.
MIC FX
/LINE FX - MIC and LINE INPUTS are routed through all effects of the current
preset.
For more information about how these settings are routed, refer to the charts on pages
21 through 23.
