TONE Row

STATUS

BUTTON

KNOB

TONE ROW

The TONE row is where the amp tone controls are located for Channel 1 or Channel 2.

The sound that you hear while adjusting these parameters will depend on the channel

status (see chart below). TONE control row parameters are Channel, Amp Gain, Bass,

Midrange, Treble, and Amp Level.

Status button

Selects one of the four channel states in the following order:

Ch1 amp - The STATUS button LED lights green and the five control knobs

light green indicating that you are listening to Channel 1 and the

control knobs affect Channel 1’s tone settings.

Ch1 warp - The STATUS button LED lights yellow and the five control knobs

light green indicating that you are listening to a warped sound

and the control knobs affect Channel 1’s tone settings.

Ch2 amp - The STATUS button LED lights red and the five control knobs

light red indicating that you are listening to Channel 2 and the

control knobs affect Channel 2’s tone settings.

Ch2 warp - The STATUS button LED lights yellow and the five control knobs

light red indicating that you are listening to a warped sound and

the control knobs affect Channel 2’s tone settings.

Knob 1

Controls the amount of Amp Gain. The Amp Gain range is from 0 to 99.

Knob 2

Controls the Bass EQ Level (boost/cut). The Bass EQ Level range is from -12dB

(-12) to 12dB (12).

Knob 3

Controls the Midrange EQ Level (boost/cut). The Midrange EQ Level range is

from -12dB (-12) to 12dB (12).

Knob 4

Selects the Treble EQ Level (boost/cut). The Treble EQ Level range is from -

12dB (-12) to 12dB (12).

Knob 5

Controls the Amp Level. The Amp Level Range is from 0 to 99.
