4-34
Waveform Capture, continued
Trigger channel
matrix
The table below shows the channels that will have waveforms recorded should rms or
transient triggers occur.
NOTE: For transient triggers, the same waveform recording options apply in separate
settings.
Trigger Type Waveforms Recorded
If RMS or Transient
event occurs
For Column 1: save waveform data for triggered channel
only V or I, and Chan D if enabled
For Column 2: save waveform data for triggered channel
pair V and I, and Chan D if enabled
For Column 3: save waveform data for all voltage
channels regardless of trigger source
For Column 4: save waveform data for all current
channels regardless of trigger source
For Column 5: save waveform data for all voltage and
current channels
