Dranetz hdpq xplorer User Manual

1-5
CH 1/ Getting Started
HDPQ Xplorer Controls, Indicators, and Connectors
Dimensions
HDPQ Xplorer is a self-contained, portable instrument weighing less than 5 pounds
with 7” (diagonal) WVGA wide screen display and measuring 2.75" (7.00 cm) deep by
10" (25.4 cm) wide by 8" (20.3 cm) high. This section identifies and describes the
controls, indicators, and connectors on all sides of the HDPQ Xplorer, shown with
rubber boot installed.
Top View
Front View
Rear View
Left Side View (with you facing front panel)
Right Side View (with you facing front panel)
