4-50
Turn Monitoring On/Off
Turn Monitoring On/Off
Start/Stop
monitoring
Once the instrument has been set up for monitoring or after reading a setup template
from memory, you can finalize and configure the monitoring process using the
parameters on the Finalize tab.
Continued on next page
Action... Result...
STEP 1: Prior to finalizing the
monitoring setup, review the
selections under Finalize tab -
Start/Stop Monitoring Conditions
and choose the setting when you
want to start/stop monitoring.
NOTE: By default, the system is
configured to start/end
monitoring using the Immediate
setting.
Under Start monitoring options:
To start monitoring, select
Immediate and click on the
Next key. Proceed to Step 2.
To delay start of monitoring,
select Delay. Use the window
provided to enter the number of
days, hours, minutes or seconds
of delay to start monitoring
from present time.
To start monitoring at a
specified date and time, select
Time/Date. Use the
corresponding windows
provided to specify the time
and date when you want
monitoring to begin.
Under Stop monitoring options:
To end monitoring when
memory storage is full, select
Storage Full.
To delay end of monitoring,
select Delay. Use the window
provided to enter the number of
days, hours, minutes or seconds
of delay to end monitoring.
HDPQ-430
