E-13

APPENDIX E/ Common Circuit Connections

Generic Circuit

Introduction

In the Generic circuit connection, the HDPQ Xplorer uses voltage channels A, B, C,

and D as differential inputs. Current probes are connected to channels A, B, C, and D.

Connection

diagram

HDPQ-906
