Dranetz hdpq xplorer User Manual

B-12
Current Probe Specifications
Current Probe Specifications
Probe guidelines
To achieve the rated accuracies, follow these guidelines:
• The conductor must be at a right angle to the probe
• The conductor must be centered in the probe core
• The jaw contact surfaces must be clean and properly aligned.
TR Series
probes
TR SERIES PROBE SPECIFICATIONS
Type: Clamp-on, AC
Installation Category
: 600 VRMS, CAT III, Pollution Degree 2
PR Series
probes
PR SERIES PROBE SPECIFICATIONS
Type: Clamp-on, AC/DC
Installation Category
: 600 VRMS, CAT III, Pollution Degree 2
Model Range Amplitude
Accuracy
±
Phase
Accuracy
+/-
Frequency
Range
Maximum
Conductor
Size
TR2500B 10A to
500A rms
100A to 500A 1% 1.5° 40Hz to
5KHz
50mm dia.
10A to 100A 2% 3°
TR2501B 100mA to
1.2A rms
1.2A 1.5% 2° 40Hz to
5KHz
15mm dia.
100mA 2% 3°
TR2510B 1A to 10A
rms
5A to 10A 1.2% 1.5° 40Hz to
5KHz
15mm dia.
100mA 1.2% 1°
TR2520B 100A to
3000A rms
1000A to 3000A 0.5% 0.5° 40Hz to
5KHz
72mm dia.
300A to 1000A 0.75% 0.75°
100A to 300A 1.5% 1.5°
TR2530B 20A to
300A rms
50A to 300A 1% 0.5° 30Hz to
5KHz
54mm dia.
20A to 50A 1.5% 0.6°
TR2540B 10A to
1000A rms
100A to 1000A 1% 0.4° 30Hz to
5KHz
54mm dia.
10A to 100A 1.5% 0.5°
TR2550B 1A to 100A
rms
10A to 100A 1% 2.5° 40Hz to
10KHz
15mm dia.
1A to 10A 2% 5°
Model Range Amplitude
Accuracy
±
Phase
Accuracy
+/-
Frequency
Range
Maximum
Conductor
Size
PR150B 15A to 150A 1% 3° DC to 5KHz 52mm dia.
PR1500B 15A to 1500A 1% 1° DC to 5KHz 52mm dia.
