1-1
CHAPTER 1
Getting Started
Overview
HDPQ
description
HDPQ
®
is Dranetz' new, advanced power quality instrument designed to facilitate
monitoring, recording and display of data on four voltage channels and four current
channels simultaneously. The HDPQ instrument builds upon the popular Dranetz PX5/
4400 family products, with more user-centric power quality management
functionalities and versatile communication options.
There are four Dranetz models of the handheld/portable HDPQ platform from which
you can choose from, depending on your application, that impacts what data and
information is displayed:
The trademark shown is hereinafter referred to as HDPQ throughout this User Guide.
The Xplorer, Xplorer-400, Guide and Visa are portable, hand-held, eight-channel
power quality meter/monitors which are very similar in operation, although the Xplorer
also has a high speed sampling board for capturing the details of very fast transients.
NOTE: This User Guide provides information on the features and functionalities for
Dranetz model HDPQ Xplorer. Functionalities of other product models are each
specified in its own user guide. For inquiries contact the Dranetz Customer Service
Department at (732) 287-3680 or 1-800-372-6832.
HDPQ Xplorer
user interface
The HDPQ Xplorer portable, hand-held, eight-channel power quality and energy meter/
monitor is capable for use on three user interface (UI):
• Local/LCD Touchscreen UI - with a WVGA wide screen liquid crystal display
(LCD), using touch screen technology.
NOTE: This User Guide provides information on this local user interface, which
includes the touch screen, LCD, and three touch buttons below the screen. The other
interfaces below may differ due to size and device capabilities, and are to be specified
in a separate document.
HDPQ
®
Xplorer
HDPQ
®
Xplorer-400
HDPQ
®
Guide
HDPQ
®
Visa
