CHAPTER 5

Instrument Settings

Overview

Introduction

This chapter describes the miscellaneous tasks that you can perform to keep the HDPQ

Xplorer running efficiently. These are tasks that you might perform only occasionally.

Instrument

Settings menu

All functions in this chapter are found under the Instrument Settings menu. Follow

these steps to display the Instrument Settings menu.

Continued on next page

Action... Result...

STEP 1: There are three (3) ways

to access the Instrument Settings

menu.

The first two ways involve the use

of the Setup Instrument icon:

1st: Upon instrument power-up

and prior to monitoring, the Home

page displays shortcut buttons,

one of which is Setup

Instrument. Proceed to Step 2.

2nd: Setup Instrument icon is

also accessible on the taskbar of

most typical screens, where

shortcuts to common instrument

functions are found.

Example: You can access Setup

Instrument from the taskbar of the

Communications setup screen.

Proceed to Step 2.

HDPQ-110a

HDPQ-302
