4-48
Exit Setup
Exit Setup
Exit Setup
At the end of the Wizard Setup, the Exit Setup screen prompts you to either accept the
setup changes or not, before going on to start monitoring (if accepted). You also have
the option to use the instrument as a meter, where monitoring setup changes are
retained without turning monitoring on.
If you jump to the Start Monitor mode while stepping through the Wizard Setup, this
screen will pop up to verify if the changes are to be accepted or not, before continuing
on to start monitoring (if accepted).
Use as Meter
Press Use as Meter if you want to finish the setup process (save setup changes) but DO
NOT turn monitoring on.
Accept
Press Accept if you want to confirm changes made in monitoring settings and start
monitoring.
Immediate monitoring
While the instrument is actively monitoring data, the message MONITORING
STATUS: ON appears in the Monitoring Status page.
You cannot change the time and date nor perform memory device operations while the
instrument is actively monitoring data. However, the rest of the function keys,
including date style and clock style, are operable even while monitoring status is ON.
NOTE: You can manually stop monitoring using the Stop Monitoring icon.
End monitoring
When monitoring ends, the message MONITORING STATUS: DONE appears on
screen.
Exit
Press Exit if you want to retain monitoring settings as they were and return to Start
Menu.
HDPQ-431
