4-46
Finalize Monitoring
Finalize Monitoring
Finalize setup
Once the instrument has been set up for monitoring or after reading a setup template
from memory, you can finalize and configure the monitoring process using the
parameters below.
Press the Finalize tab. Prior to finalizing the monitoring setup, you have the option to:
Indicate when to start/stop recording - begin monitoring immediately or at a
specified time and date
Manage files in memory
View the setup summary
Enter additional information about the site that is to be saved with the setup
Start/Stop Monitoring Conditions
Under the Start monitoring options, select one from the following:
Immediate - to begin monitoring immediately
Delay - use the window provided to enter the number of days, hours, minutes or
seconds of delay to start monitoring from present time
Specified time and date - use the corresponding windows provided to specify the
time and date when monitoring begins
Under the Stop monitoring options, select one from the following:
Storage full - to end monitoring when memory storage is full
Delay - use the window provided to enter the number of days, hours, minutes or
seconds of delay to end monitoring
Specified time and date - use the corresponding windows provided to specify the
time and date when monitoring ends
Never - to keep monitoring without specified end date/time
NOTE: You can manually stop monitoring using the Stop Monitoring icon.
Memory
Under Memory:
Free Space - indicates the remaining space in memory in gigabytes
Used Space - indicates the memory space used in gigabytes
Continued on next page
