Dranetz hdpq xplorer User Manual

5-31
CH 5/ Instrument Settings
Factory default
settings
Dranetz has set the default values for the various parameters of the HDPQ Xplorer.
Scale Factors:
1:1 for V and I, channels A, B, C, D
Circuit Type:
Three Phase Wye
Mode of Operation:
Monitor Off
Nominal Value:
measured V, I, frequency
Monitoring Mode:
Standard Power Quality
Advanced Operations:
individual limit setups
Transient Limits:
intantaneous peak = 3X nominal V, waveshape = 10% ,
rms dev = 10% , fast transient = 3X nominal V, none for I
RMS Variation Limits:
10% Very Low, 90% Low, 110% High for voltage; none for
current
Journal Limits:
journalling By Time for the various parameters
Triggers:
all V trigger; all V and I channels
Timed Intervals
Power Values:
Power Values Interval: 10 minutes
Demand and Energy:
Demand Sub-Interval: 5 minutes
Demand Interval: 15 minutes
Harmonics Journal Interval:
10 minutes
Flicker:
Pst (Short Term) Interval: 10 minutes
Plt (Long Term) Interval: 2 hours
Site Name:
HDPQ Xplorer Site
Date:
mm/dd/yy
Language:
English
Display
:
Backlight Timer:
1 minute
Brightness:
70%
Password Protection:
OFF
