APPENDIX A/ Optional Accessories
Current probes
Several Dranetz current probes, the TR (B Series) probes and PR (B Series) probes, can
be used with the HDPQ Xplorer. HDPQ Xplorer also supports the DRANFLEX (XLB
and MHB Series) probes. Refer to Chapter 2 for actual photos of these probes.
TR-2501B, TR-2500B, TR-2510B, TR-2550B
: These probes models will measure rms
currents from 100mA to 1.2A, 10A to 500A, 1A to 10A, and 1A to 100A respectively.
They plug directly into any of the current inputs on the top panel of the instrument.
TR-2530B, TR-2540B, TR-2520B
: These probe models will measure rms currents in
ranges of 20A to 300A, 10A to 1000A, and 100A to 3000A respectively. They plug
directly as well into any of the current inputs on the top panel of the instrument.
PR B-Series Current Probes
: The PR150/SP1B, PR150/SP2B, PR1500/SP7B and
PR1500/SP8B current probes have been designed for accurate non-intrusive
measurements of AC and DC current. PR150/SP1B and PR150/SP2B current probes
measure currents in the range of 15A to 150A AC/DC. PR1500/SP7B and PR1500/
SP8B probes measure currents in the range of 150A to 1500A AC/DC.
The PR150/SP1B and PR1500/SP7B current probes require an external 9V power
supply and each probe can be powered by a separate adapter or by one adapter and an
optional RR/PS/4A adapter cable which allows the connection of four (4) PR series
probes to a single 9VDC source.
The PR150/SP2B, and PR1500/SP8B current probes are supplied with a 9V battery and
will operate on battery power typically for approximately 75 hours of continuous
operation.
DRANFLEX XLB Series Current Probes
: DRANFLEX XLB Series has current probe
models that allow current measurements in Single Phase circuit and in 3 Phase circuit.
DRANFLEX3000XLB are Single Phase current probes that allow current
measurements in the range of 30 to 3000A full scale. These probes are available in
three sizes: 24" probe length - conductor(s) up to 8" diameter; 36" probe length -
conductor(s) up to 11" diameter; 48" probe length -conductor(s) up to 17" diameter.
DRANFLEX6000XLB also are Single Phase current probes that allow current
measurements in the range of 60 to 6000A full scale. These probes are available in
three sizes: 24" probe length - conductor(s) up to 8" diameter; 36" probe length -
conductor(s) up to 11" diameter; 48" probe length -conductor(s) up to 17" diameter.
DRANFLEX3003XLB are 3 Phase current probes that allow current measurements in
the range of 30 to 3000A full scale. These probes are available in three sizes: 24" probe
length - conductor(s) up to 8" diameter; 36" probe length - conductor(s) up to 11"
diameter; 48" probe length - conductor(s) up to 17" diameter.
