A-9
APPENDIX A/ Optional Accessories
Dran-View 7
application
(continued)
• Monitoring mode specific reports in both the automatic and custom mode
• Format templates for consistent formatting
• Timeplots/waveshape/magnitude-duration & DFT charts
• Rescue kit (repair data)
• Separate harmonic scaling for voltage, current, and power
• Automatic updates via the Internet
• Export Data to Excel
Following are the features and highlights of the Dran-View 7 Enterprise:
All the features of the Dran-View 7 Pro, plus:
• Multi-site presentation/report writing - supports presentation of many simultaneous
data sets
• Multi-site mathematical formulas
• Additional advanced report writing modules
• Drag-and-drop user interface
• Customizable toolbars, menus and keyboard shortcuts
• Data removal
• Data aware notation text balloons in your charts
• Timeplot and harmonics calculations from waveshapes
• Images and photographs can be inserted
• Imports COMTRADE files (including data from protection relays)
• Imports PQ data from text/spreadsheets
• Snapshots to create print queues or restore program status
• Enhanced DFT features for selecting and analyzing harmonics
Customer
service and
support
For more information on the Dran-View software package, or for installation or
operating assistance with the Dran-View software, please contact the Dranetz Customer
Support at (732) 287-3680 or 1-800-372-6832.
