Dranetz hdpq xplorer User Manual

E-3
APPENDIX E/ Common Circuit Connections
Qualifiziertes Personal, das an bearbeiten oder herausgestellte angezogene
elektrische Leiter sich nähern, muß anwendbare Sicherheit bezogener Arbeit
Praxis und Verfahren einschließlich passende persönliche schützende Ausrüstung
gemäß dem Standard für elektrische Sicherheitsauflagen für Angestellt-
Arbeitsplätze (ANSI/NFPA 70E-2012) der Vereinigten Staaten und alle
zusätzlichen Arbeitsplatzsicherheitsauflagen folgen, die auf Ihre Installation
anwendbar sind.
WARNING
To avoid the risk of electric shock or burns, always connect the safety (or earth)
ground before making any other connections.
WARNING
To reduce the risk of fire, electrical shock, or physical injury it is strongly
recommended to fuse the voltage measurement inputs.
Fuses must be located as close to circuit connection as possible to maximize
protection.
WARNING
For continued protection against risk of fire or shock hazard replace only with
same type and rating of fuse.
WARNING
Do not replace fuse again if failure is repeated. Repeated failure indicates a
defective condition that will not clear with replacement of the fuse. Refer
condition to a qualified technician.
Safety
precautions
The following safety precautions must be followed whenever any type of voltage or
current connection is being made to the HDPQ Xplorer.
• Wear proper Personal Protective Equipment, including safety glasses and insulated
gloves when making connections to power circuits.
• Hands, shoes and floor must be dry when making any connection to a power line.
• Before each use, inspect all cables for breaks or cracks in the insulation. Replace
immediately if defective.
• Set the HDPQ Xplorer power switch to Off.
• Before connecting to electric circuits to be monitored, open their related circuit
breakers or disconnects. DO NOT install any connection of the HDPQ Xplorer to
live power lines.
• Connections must be made to the HDPQ Xplorer first, then connect to the circuit to
be monitored.
• If the equipment is used in a manner not specified in this User Guide, the protection
provided by the equipment may be impaired.
Continued on next page
