3-27
CH 3/ Real Time Data
Sample 3-Phase,
three wire delta
rotation
(continued)
The following diagrams describe the positive phase rotation of voltage and current
phasors (for Resistive, Inductive and Capacitive loads) for a three phase, three wire
delta connection. An arrow head on the line indicates direction pointing toward the
load.
Three phase vectors are displayed as three lines, 120 degrees apart in an Inductive load
Three phase vectors are displayed as three lines, 120 degrees apart in a Capacitive load
Phasor
diagrams
Refer to Appendix E for the diagrams that describe the voltage and current phasors for
the standard type of power connections.
HDPQ-323
HDPQ-324
