SHANGHAI ESURVEY GNSS CO., LTD.
8
2.6.1 Replace and Mount the Battery
To replace and mount the battery, do the following:
1. Turn the battery lock button to unlock status :
2. Pull the battery lock button out to open the battery cover.
3. Remove the battery by pulling it toward you.
4. Insert the new battery to the instrument.
5. Close the battery cover, and turn the battery lock button to lock status.
2.6.2 Recharge the Battery
New battery or battery that has not used for several months should be recharged for at
least 10 hours to attain best status.
The status of the battery charging:
Red light is always on: in charging.
Green light is always on: charging is completed.
At this time, please recharge the battery continuously for another 1~2 hours, which
is good for the battery.
Red light flashes: waiting for charging, without a load, poor contact or battery failure
To recharge the battery, do the following:
1. Connect the charger connector to the battery:
2. Plug the charger on 220V AC power supply. The red lamp becomes lighting.
At this time, if the red light flashes, please take off the battery charger and plug it on
220V AC power supply after a while.
