SHANGHAI ESURVEY GNSS CO., LTD.
50
To set area and volume, do the following:
1. To enter Program menu page, press MENU and F1 or 1.
2. Press PAGE to go to the second page, and press F2 or 6:
o : it indicates that settings are done.
o : it indicates that settings are not done.
3. Do the following:
a. Set a Job
If you have done it before, you can skip it.
b. Set the Station
If you have done it before, you can skip it.
c. Set the Orientation
If you have done it before, you can skip it.
d. Start Area and Volume
5.2.6.1 Set a Job
See 5.2.1.1 Set a Job for details.
5.2.6.2 Set the Station
See 5.2.1.2 Set the Station for details.
5.2.6.3 Set the Orientation
See 5.2.1.3 Set the Orientation for details.
5.2.6.4 Start Area and Volume
To start area and volume, do the following:
1. To enter AREA & VOLUME display, in AREA & VOLUME display, press F4 / 4:
