SHANGHAI ESURVEY GNSS CO., LTD.
21
4.10 Main Settings
Its function is totally same with the SETS menu page.
See 5.3 Setting Menu for details.
4.11 Tracking
It is used to enable / disable the tracking measurement mode. And it can only be activated
from within the same EDM mode and prism type.
Note: The last setting remains valid when the instrument is powered off.
To select Tracking and enable / disable the tracking measurement mode, press Fn and
do one of the following:
Press PAGE to go to the third page, and press F3.
Press 02.
The display shows Take Measure Switched On / Take Measure Switched Off for
approximately 1s.
4.12 Light On/Off
It is used to turn on or off the display illumination.
To turn on / off the light, press Fn and do one of the following:
Press PAGE to go to the third page, and press F4.
Press 0 and 3.
The display illumination is automatically on / off.
4.13 Units
It is used to display the current distance and angle units and give the possibility to change
them by ◀ / ▶.
To set the units of distance and angle, do the following:
1. To enter the setting display, press Fn, and press PAGE to go to the fourth page:
2. Set the distance unit and angle unit.
About the supported units, see 5.3 Setting Menu for details.
3. Press F4 SET for conformation.
