| Using the Web Interface
Navigating the Web Browser Interface
– 106 –
MSTP Multiple Spanning Tree Algorithm 253
Configure Global 253
Add Configures initial VLAN and priority for an MST instance 253
Modify Configures the priority or an MST instance 253
Show Configures global settings for an MST instance 253
Add Member Adds VLAN members for an MST instance 253
Show Member Adds or deletes VLAN members for an MST instance 253
Show Information Displays MSTP values used for the bridge
Configure Interface 257
Configure Configures interface settings for an MST instance 257
Show Information Displays interface settings for an MST instance 257
Traffic
Rate Limit Sets the input and output rate limits for a port 259
Storm Control Sets the broadcast storm threshold for each interface 260
Auto Traffic Control Sets thresholds for broadcast and multicast storms which can be
used to trigger configured rate limits or to shut down a port
262
Configure Global Sets the time to apply the control response after traffic has
exceeded the upper threshold, and the time to release the control
response after traffic has fallen beneath the lower threshold
264
Configure Interface Sets the storm control mode (broadcast or multicast), the traffic
thresholds, the control response, to automatically release a
response of rate limiting, or to send related SNMP trap messages
265
Priority
Default Priority Sets the default priority for each port or trunk 269
Queue Sets queue mode for the switch; sets the service weight for each
queue that will use a weighted or hybrid mode
270
Trust Mode Selects DSCP or CoS priority processing 276
DSCP to DSCP 277
Add Maps DSCP values in incoming packets to per-hop behavior and
drop precedence values for internal priority processing
277
Show Shows the DSCP to DSCP mapping list 277
CoS to DSCP 279
Add Maps CoS/CFI values in incoming packets to per-hop behavior and
drop precedence values for priority processing
279
Show Shows the CoS to DSCP mapping list 279
PHB to Queue 273
Add Maps internal per-hop behavior values to hardware queues 273
Show Shows the PHB to Queue mapping list 273
DiffServ 283
Configure Class 284
Add Creates a class map for a type of traffic 284
Table 6: Switch Main Menu (Continued)
