| Using the Web Interface
Navigating the Web Browser Interface
– 105 –
Protocol 216
Configure Protocol 217
Add Creates a protocol group, specifying supported protocols 217
Show Shows configured protocol groups 217
Configure Interface 218
Add Maps a protocol group to a VLAN 218
Show Shows the protocol groups mapped to each VLAN 218
IP Subnet 220
Add Maps IP subnet traffic to a VLAN 220
Show Shows IP subnet to VLAN mapping 220
MAC-Based 222
Add Maps traffic with specified source MAC address to a VLAN 222
Show Shows source MAC address to VLAN mapping 222
Mirror 224
Add Mirrors traffic from one or more source VLANs to a target port 224
Show Shows mirror list 224
MAC Address 227
Learning Status Enables MAC address learning on selected interfaces 227
Static 229
Add Configures static entries in the address table 229
Show Displays static entries in the address table 229
Dynamic
Configure Aging Sets timeout for dynamically learned entries 230
Show Dynamic MAC Displays dynamic entries in the address table 231
Clear Dynamic MAC Removes any learned entries from the forwarding database and
clears the transmit and receive counts for any static or system
configured entries
232
Mirror Mirrors traffic matching a specified source address from any port
on the switch to a target port
233
Spanning Tree 235
Loopback Detection Configures Loopback Detection parameters 238
STA Spanning Tree Algorithm
Configure Global
Configure Configures global bridge settings for STP, RSTP and MSTP 240
Show Information Displays STA values used for the bridge 245
Configure Interface
Configure Configures interface settings for STA 246
Show Information Displays interface settings for STA 250
