Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 3-22 Chapter 3. Commands
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Command Conventions and Options
COMMAND CONVENTIONS
The following conventions are used for the command options.
Convention
Usage
italics Items shown in italics are variables and requires you to supply the text.
For example, when text appears in italics, you should type the desired
text.
[brackets] Items in brackets are optional information that may be used with a
command. To include optional information, type a space after the
command name and then type the information within the brackets. Do
not type the brackets themselves.
COMMAND OPTIONS
Command options provide a command with extra information that affect the operation of
the command. If options are omitted, the command either prompts you to supply them or
uses a default value. The valid options for a command may be one or more of the
following.
Note: Channels are identified by a channel type, node number, and channel number.
Example: Channel A0001,
A (channel type) represents an analog channel
00 (node number) represents the Master Node
01 (channel number) represents channel #01
Option
Description
channel_type A single alpha character that refers to a channel type. Valid
characters include:
A for Analog Channels
B for Binary Channels
E for Energy Management Channels
F for Function Channels
L for LED Channels
R for Relay Channels
U for User Channels
node_number The number assigned to the node.
channel_number The number assigned to the channel.
channel_designator channel_type [node_number] channel_number, example A1201.
channel_range channel_type [node_number] channel_number – [node number]
channel_number, example A1-201.
node_designator Nnode_number, example N12.
