Emerson LMS1000 User Manual

User Instructions Section 5847
Spec. Nos. 586505000 and 5865055000 (Model LMS1000) Issue AL, July 24, 2006
Chapter 3. Commands Page 3-11
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Vortex
®
Power System (VPS) Interface Commands
This section provides an alphabetical list of all Vortex Power System (VPS) Interface
commands, with a short description of each command.
Vortex
®
Power System (VPS)
Interface Commands
Description
ALARMS VORTEX
list active Power System alarms
ALARMS VORTEX LVD
list active LVD alarms
ALARMS VORTEX MCA
list active MCA alarms
ALARMS VORTEX PCU<n>
list active PCU alarms
ALARMS VORTEX SHUNT
list active SHUNT alarms
ALARMS VORTEX SUBSYSTEM
list active subsystem type alarms
ALARMS VORTEX SYSTEM
list active system type alarms
DOWNLOAD VORTEX
dump Vortex Power System configuration using XMODEM protocol
HELP VORTEX
list of Vortex Interface commands with a description of each
PRCONFIG VORTEX
list settings and equipment inventory
PRCONFIG VORTEX
INVENTORY
list equipment inventory
PRCONFIG VORTEX
SETTINGS
list settings
SCAN VORTEX
list present status of Vortex Power System
SCAN VORTEX LVD
list present status of LVD circuits
SCAN VORTEX MCA
list present status of MCA
SCAN VORTEX PCU<n>
list present status of specified PCU
SCAN VORTEX SUBSYSTEM
list present status of subsystem data
SCAN VORTEX SYSTEM
list present status of system data
SET VORTEX
configure Vortex Power System settings
SET VORTEX INTERFACE
Enable/Disable Vortex interface
SET VORTEX LVD<n<t>>
DISCONNECT
set specified LVD disconnect voltage settings
SET VORTEX LVD
RECONNECT
set LVD reconnect voltage setting
SET VORTEX MESSAGE MCA
set MCA custom message
SET VORTEX MESSAGE
PCU<n>
set specified PCU custom message
SET VORTEX PASSWORD
set MCA logon password
SET VORTEX PCU<n>
turn specified PCU On or Off
SET VORTEX SUBSYSTEM
CALVOLT
set subsystem calibration voltage
SET VORTEX SUBSYSTEM
FACTORYCAL
set subsystem cal. voltage to factory default
SET VORTEX SUBSYSTEM
HIVALM
set subsystem High Voltage alarm
SET VORTEX SUBSYSTEM
LVALM
set subsystem Low Voltage alarm
