LMS1000 Commands Description
SET CMD <n>
set programmable commands
SET COM
set local comm port configuration
SET DATE <mm/dd/yy>
set date where mm = month, dd = date, yy = year
SET DEFAULTS
set system default parameters
SET EFF
set Energy Management parameters
SET EMAIL
set Email Alarm Notification Parameters
SET GATEWAY
set GATEWAY port communications data rate
SET INFO <n>
configure information pages
SET LED <n>
turn LED on
SET LIMITS <tn>
set channel alarm limits
SET MAIL
send mail to users
SET MODE
modify configuration of TL1 port settings
SET PERIODS <tn>
set time periods
SET PHONE
set user phone numbers
SET PROGRAM <tn>
configure control programs
SET REPORT
set system alarm reporting parameters
SET RLY <n>
energize relay
SET SEQUENCE
set AC & Standby sequencer parameters
SET STATUS <n>
configure status page
SET SYSTEM
configure all settings
SET TIME <hh:mm:ss>
set time where hh = hours, mm = minutes, ss = seconds
SET TIMEOUT <n>
set user timeout
SET UNIT
set unit name and number
SET USERS <n>
configure a user
SET VI
sets the channels that display system voltage and system current
STATS
list channel statistics
STATUS <n>
show status page
TIME
show date and time
TIMEOUT
show user timeout
UNIT
show unit name and number
UPLOAD
configure the system by uploading file using XMODEM protocol
UPLOAD TFTP
allows transfer of configuration information to the system from any networked
personal computer capable of uploading and downloading a file to a disk using
the TFTP Protocol
USERS <n>
list user configuration
VI
show Plant Voltage and Load
where: < > anything enclosed in brackets is optional.
n is a valid number.
t is a type A, B, E, F, G, L, R; for Analog, Binary, Energy Management, Function, Group, LED, or
Relay.
