Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-22 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
VIEWING AND CLEARING THE EVENT LOG
The event log maintains in battery-backed memory a chronological listing of the 500
latest events that have occurred in the system (and in an MCA, if connected). An event
is defined as any change to the system configuration or to critical programming
parameters of the system, and are described below.
Note: The event log will not
record a report failure if there is no phone number entered
in a user’s configuration, and the system attempted an alarm report to this user.
LMS1000 Events:
1) The unit has been reset.
2) The unit's default settings are reset (by user or unit).
3) A user logs on to the unit.
4) A failed logon attempt has occurred.
5) The user setup has been changed.
6) The date or time has been changed.
7) The alarm log has been cleared.
8) The statistics have been cleared.
9) Alarms have been cancelled or un-cancelled (SET/CLR ACO).
10) A particular channel has been configured.
11) A particular LED or relay has been set (forced) or cleared.
12) The event log has been cleared.
13) A time period has been set.
14) A user phone number has been set.
15) The unit name or number has been set.
16) An information page has been set.
17) Relay circuit card failure.
18) Analog circuit card failure.
19) A new alarm report completed or failed.
20) A user report completed or failed.
21) User channels set.
22) System uploaded.
23) Status page set.
24) Programmable command set.
25) User timeout set.
26) Unreported system alarms have been acknowledged (ACK).
27) Pager report attempted.
28) Function, LED, or relay channel program line cleared.
29) Energy management enabled, disabled, or configured.
30) TL1 Report Messages.
31) System Identifier Configured.
32) TL1 Report Messages enabled or disabled.
33) "4 chan Relay bd <#n> fail".
34) "Com link to MCA broken".
35) "Chn <type, node#, channel#> statistics cleared".
36) "Function channel stats cleared".
37) "Analog channel stats cleared".
38) "System reset issued".
39) "4 chan Binary bd <#n> fail".
40) "8 chan Binary bd <#n> fail".
41) "Temperature bd <#n> fail".
42) "Temp bd <#n> sensor <#n> fail".
43) "4 ch A/D <#n> converter <#n> fail".
