Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 3-226 Chapter 3. Commands
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
SET STATUS
Description: Permits configuration of related channel scan information into a convenient
single page format consisting of 18 lines. Up to sixteen (16) status pages can be
configured.
Command Level: 6
Syntax: SET STATUS [n]
SE ST [n]
Comments: The first line is reserved for the page name, with a maximum page name
length of 30 characters. The remaining 17 lines can be either programmed to display
header information, which is the names of the columns displayed during a scan, or actual
scan data information from a particular channel. With this capability, a group of different
channels can be scanned and appear together on a status page.
Refer to Table 3-3 below for a guide to character entries to display either header
information or scan information for particular channels.
SCAN HEADER INFORMATION SCAN CHANNEL DATA
ENTER HEADER TYPE ENTER CHANNEL TYPE
A analog A[node_number_channel_number] analog
B binary B[node_number_channel_number] binary
E energy management E[channel_number] energy management
F function F[channel_number] function
L LED L[channel_number] LED
R relay R[node_number_channel_number] relay
Table 3-3
SET STATUS Character Entries
Notes: none
Related Commands: STATUS
