This is the time when the triggering event occurred. The format for this parameter is
HOD-MOH-SOM (Hour-Of-Day - Minute-Of-Hour - Second-Of-Minute). HOD ranges from
0 to 23. MOH and SOM range from 0 to 59. A NULL value means this parameter and
the <ocrdat> parameter are not applicable.
<locn>, <dirn>
These parameters do not apply to LMS1000. A NULL value is inserted for them when
the <tmper> parameter has a value other than NULL.
<tmper>
This is the accumulation time period for Performance Monitoring (PM) parameters. It
represents the length of time the condition has been active. If the condition or state is
normal, it defaults to NULL. The format for this parameter is VAL-UN, where valid values
for VAL (value) and UN (unit) are:
VAL (value)
UN (unit)
1 DAY (day)
1 to 24 HR (hour)
1 to 1440 MIN (minute)
<conddescr>
This parameter is a text message which provides a detailed description of the alarm,
event, or condition. It is an ASCII string enclosed within a pair of escaped quotes (\"). It
may also be used to describe any action to be taken as a result of the condition. For this
application, values are derived from the CONDITION DESCRIPTION parameter of the
LMS1000 channel or limit configuration with which the alarm condition is associated. If
the channel or limit parameter has not been configured, a NULL will be inserted for this
parameter.
