Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 5-14 Chapter 5. Troubleshooting and Repairing LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
CPU Circuit Card
J4
(located behind bracket)
(Main Cabinet Only)
RS-232 Connector
Grounding Screw
(Main Cabinet Only)
Main Cabinet Shown.
Expansion Cabinet Similar,
Except J4 and Grounding
Screw.
582140000
Primary and Secondary Bay
Primary LMS
CPU Circuit Card
(P/N 521185 in 582140000)
(P/N 514024 in 586505000
and 586505500)
Secondary LMS
CPU Circuit Card
(P/N 506153)
586505000
Main Cabinet
(586505500 similar)
Figure 5-1
CPU Circuit Card Replacement
