Multiple Projector Operation Settings - Multi-Projection Menu

204

Setting Options Description

Color Matching Adjustment Level

Red

Green

Blue

Brightness

Corrects the difference between the tint

and brightness of each projected image.

RGBCMY — See the Image menu table for details on

the RGBCMY settings.

Reset Multi-

Projection Settings

— Resets all adjustment values on the

Multi-Projection menu to their default

settings.

gg Related Links

• "Using Multiple Projectors" p.112

• "Projector Installation Settings - Installation Menu" p.185

• "Image Quality Settings - Image Menu" p.180

• "Projector Administration Settings - Management Menu" p.192

• "Projector Feature Settings - Operation Menu" p.189

• "Blending the Image Edges" p.116

• "Adjusting the Black Level" p.118

• "Connecting Multiple Projectors of the Same Model" p.36
