Optional Accessories and Replacement Parts

244

External Speaker ELPSP02

External self‑powered speaker.

HDBaseT Transmitter ELPHD01

Use when sending an HDMI signal over a long distance. (HDCP 2.2 is not

supported)

Android TV

™

device ELPAP12

(EB‑‑L735U/EB‑‑L730U/EB‑‑L635SU/EB‑‑L630SU/EB‑‑L630U/EB‑‑L530U)

Use this streaming media player to watch online content.

Replacement Parts

Air filter ELPAF56

Use as a replacement for used air filters.
