Using Multiple Projectors
120
Modifying the Black Level Adjustment Area
If there are areas where the color does not match after adjusting the Black
Level setting, you can adjust them individually.
a
Select Area Correction in the Black Level setting and press [Enter].
b
Select Start Adjustments and press [Enter].
Boundary lines indicating where images overlap are displayed. The lines
are displayed based on the Edge Blending setting.
c
Use the arrow buttons to select the boundary line you want to adjust.
Then press [Enter].
The selected line is displayed in orange.
d
Use the arrow buttons to adjust the line position. Then press [Enter].
e
Use the arrow buttons to select the point you want to move. Then press
[Enter].
The selected point is displayed in orange.
a
You can change the number of the displayed points using the
Points setting.
f
Use the arrow buttons to move the point.
g
To continue to move another point, press [Esc] and then repeat steps 5
and 6.
h
To adjust another boundary line, press [Esc] until the screen shown in
step 3 is displayed.
i
When you are finished, press [Menu].
Matching the Image Colors
You can match the display quality of multiple projectors that will project next
to each other.
Before you begin, turn on all the projectors so you can select image quality
settings that match on the unified screen.
